Zinc Plated T Shape Clip Bolt KSYXLS15 manufacturer from China Kunshan Alex Railway Fastening Co.,Ltd.

Price:	1.2 USD
Payment Terms:	T/T,L/C
Place of Origin:	Jiangsu, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: KSYXLS15

Production Capacity: 600, 000PCS/Month

Delivery Date: 20days

Surface Finish:: Plain, Black, Phosphate, Zi...

Means of Transport: Ocean,Land,Air

Packing: Double-Layer Woven Bag, Fum...

Brand Name: Alex

Sizes:: 3/8", 1", 1 3/8", 1 1/2" or...

Packing:
Double-Layer Woven Bag, Fumigation-Free Pallets
Standard:
SAE J429
HS Code:
7318150000

Product Details

Model NO.:KSYXLS15

Material:Carbon Steel

Connection:Common Bolt

Head Style:Round

Standard:DIN, ANSI, GB, JIS, BSW, GOST

Grade:8.8

Application:Building

Finish:Black

Raw Material:45#, 40cr

Certificate:ISO9001:2008

Std No.:SAE J429

Surface Finish:Plain, Black, Phosphate, Zinc , HDG

Sizes:3/8", 1", 1 3/8", 1 1/2" or Others

Inspection:Internal and 3rd Parties

Inspection Reports:Chemical Composition, Physical Property and Sizes

Sample Policy:Sample Free, Freight Collect

Process Control:Internal

Production Update:Weekly Reports Will Be Provided

Additional Info.

Packing:Double-Layer Woven Bag, Fumigation-Free Pallets

Standard:SAE J429

HS Code:7318150000

Production Capacity:600, 000PCS/Month

Product Description

Standard: ASTM, DIN, BSW, GB, JIS, UIC, Russian or drawings from customers.
Materail: Carbon steel or stainless steel, Q195, Q235, 35#, 45#, 35CrMo, 42CrMo, 40Cr etc.
Surface Finish: plain (oiled), hot dip galvanized, white zink plated, yellow zink plated, black, dacromet, geomet or others specified by the customers.

D	L	I	Threads Per Inch
Nom. Dia. Over Thread	Length Under Head	Min. Thread Length	Threads Per Inch
7/8	Under 7",in steps of 1/4" From 7" to 10" in steps of 1/2"	2"	9
1		2-1/4"	8
1-1/8		2-1/2"	7
Additional Sizes Now in Use But Not Recommended for New Designs
13/16	Same as above	1-7/8"	10
15/16		2-7/8"	9
1-1/16		2-3/8"	8
Note: All dimensions given in inches. Tolerances: Length (L) ± 1/8", Neck (O and R1) ± 0.0313", Head (A and H) ± 0.0625", R2 ±0.0175" In ordering bolts, specify the nominal diameter, "D" , over the threads and not the body diameter.

Kunshan Alex Railway Fastening Co., Ltd manufactures railway fasteners and standard components. As a leading railway fasteners manufacturers in China,with production license of Chinese railway Ministry, advanced technology, high precision inspection instruments and service, our products have been widely exported the USA, Germany, Spain, Japan, Australia, Italy, Netherlands, Belgium, Poland, the UK, India, and South Africa etc.

We can provide products according to customers drawings and samples.Our main products are as following:
1. Screw spike/Coach screw/Drive screw/Sleeper Screw, Dog spike/Railroad spike/Lock spike/Cut spike,etc.
2. Rail clip/ Tension clamp/ E, R, SKL clip/ Railroad Clip/ Deenik clip
3. Swivel Bolts/ Track Bolt/ Special bolts/ U bolts/ J bolts/ Anchor bolts/ Foundation bolts/ Stud bolts/ Rod bolts/ Curved bolts/ Tunnel bolts
4. Tie plate/ Base plate / Rail plate/ Rail fixing base/ Rail Pads/ Sole plate/ Sole pad
5. Fish plate / Joint bar / Rail joint/ Splice Bar
6. Track bolt/ T bolt / Rail bolt/ Clamp bolt/ Inserted bolt/ Clip bolt/ Fish bolt/ Square bolt/ Rod bolt /Rail joint bolt
7. Clamp plate/ Rail spring clamp/ Anchor plate/ Steel clip
8. Rail Shoulder/ Rail sleeper Inserts/ Rail Anchors for rail sleepers
9. Plastic dowel / Guide plate/ Nylon insert
